Powered by Steam, optimized for gaming in any form.

The Steam Hardware family officially expands in early 2026. Just like Steam Deck, all are optimized for gaming on Steam, and all are designed to help players get even more out of their Steam Library.

Made for Steam Controller

Steam Machine comes with a built-in wireless adapter, just for pairing with Steam Controller. (Up to four with a single adapter!) This means you can pair your Steam Controller without its puck, and you can wake your Steam Machine without leaving your couch.

Customizable for Steam Input

Steam Controller was designed with all the inputs for all your games. Paired with Steam Input, it’s the ultimate customizable controller. Thanks to its input parity with Steam Deck, Steam Controller will be pre-populated with community configurations for thousands of games from day one, or you can make and share your own.

Specification:

Tech Specs for Steam Machine

General

CPU: Semi-custom AMD Zen 4 6C / 12T  - up to 4.8 GHz, 30W TDP

GPU: Semi-Custom AMD RDNA3 28CUs - 2.45GHz max sustained clock, 110W TDP

RAM: 16GB DDR5 + 8GB GDDR6 VRAM

Power: Internal power supply, AC power 110-240V

Storage: 512GB NVMe SSD

Connectivity

Wi-Fi: 2x2 Wi-Fi 6E

Bluetooth: Bluetooth 5.3 dedicated antenna

Steam Controller: Integrated 2.4 GHz Steam Controller wireless adapter

I/O

Displays: DisplayPort 1.4

Up to 4K @ 240Hz or 8K@60Hz

Supports HDR, FreeSync, and daisy-chaining

HDMI 2.0

Up to 4K @ 120Hz

Supports HDR, FreeSync, and CEC

USB

Two USB-A 3.2 Gen 1 ports in the front

Two USB-A 2.0 High speed ports in the back

One USB-C 3.2 Gen 2 port in the back

Networking: Gigabit ethernet

LED Strip: 17 individually addressable RGB LEDs for system status and customizability

Size and Weight

Size: 152 mm tall (148 mm without feet), 162.4 mm deep, 156 mm wide

Weight: 2.6 kg

Software

Operating System: SteamOS 3 (Arch-based)

Desktop: KDE Plasma

Tech Specs for Steam Controller

Controls and Input

Gamepad controls

A B X Y buttons

D-pad

L & R analog triggers

L & R bumpers

View & Menu buttons

Steam & QAM buttons

4x assignable grip buttons

Thumbsticks: 2x full-size magnetic thumbsticks (TMR) with capacitive touch

Haptics

4x haptic motors

2x LRA haptic motors in trackpads for HD tactile feedback

2x High output LRA haptic motors in grips for HD game haptics including rumble

Trackpads: 2x 34.5mm square trackpads with haptic feedback Pressure-sensitive for configurable click strength

Gyro: 6-axis IMU

Grip Sense: 2x capacitive areas along back of Steam Controller handles

Connectivity

Steam Controller Puck

2.4GHz Wireless connection

~8ms full end-to-end, 4ms polling rate (measured at 5m)

Up to 4 Steam Controllers per Steam Controller Puck

Steam Controller Puck connects to PC via USB-C

Bluetooth: Bluetooth 4.2 minimum, 5.0 or higher recommended

USB: USB-C tethered play

Power

Charging

Steam Controller Puck charging interface

USB-C connector

Battery

8.39 Wh Li-ion battery

35+ hours of gameplay*

Battery life for tracked gameplay with Steam Frame is reduced
